Specification Of Lubrication pump ---Raydafon:
Item:
The EP-MALP-O1 chain thin oil lubrication system offers significant advantages for maintaining optimal performance in machinery. Its ample pressure oil supply ensures timely lubrication for a large number of widely distributed lubrication points. This effective distribution not only provides necessary lubrication but also helps manage friction heat generated during operation.
Additionally, the system effectively removes mechanical impurities, such as metal abrasive particles, from the friction surfaces. As the oil circulates, it washes away these contaminants, promoting a cleaner operating environment. This comprehensive approach to lubrication enhances overall performance by reducing friction and wear, minimizing the consumption of wearing parts, and lowering power consumption. Ultimately, the EP-MALP-O1 system contributes to extending the service life of equipment, making it an essential component for efficient machinery operation.
| Name | EP-MALP-O1 Series Rotating Drive Piston Pumps Lubrication Pump for POTTINGER Baler Replacement of BEKA 10138503/AZU |
| Output rate | Max. 0.06 cm³ per stroke one outlet |
| Regulation of Output | 1 - 6 individual outlets 7 - 12 outlets in pairs |
| Input speed | Std 22 r.p.m (11/42/80 r.p.m OPT) |
| Operating pressure | max. 15bar |
| Suction height | max. 2000 mm |
| Lubricant | Oil |
| Viscosity range | 25 - 1500 mm² /s |
| Temperature range | Medium -30 - 70 °C Ambient -35 - 40 °C |
| No. of outlets | Max. 12 |
| Outlet type | See order key |
| Sense of rotation | Optional |
| Weight | 1.5kg |
| Varnish | Black(pump body and housing) |
We developed and produced many tractor spare parts for European/Jananese Tractors .
Tractor Model we can supply: B1500/1400,B5000,B6000, B7000, TU1400, TX1400, TX1500, YM F1401, YM1400 ETC.
The parts for example: Gearboxes, Tyres, rim Jante, Kit coupling KB-TX 3 point linkage. Exhaust pipe Steering wheel. Kit coupling YM F14/F15, gear shaft, PTO shaft, PTO cardan, key, regulator ect.
Most of the spare parts are with stock. If you are interested in, please feel easy to contact me.
Other relevant parts for cars or machinery we have made in our workshop are as follows:
Drive shaft parts and assemblies,
PTO GEARBOX,
Universal joint parts and assemblies,
PTO drive shafts,
Spline shafts,
Slip yokes,
Weld yokes,
Flange yokes,
Steering columns,
Connecting rods,
etc.
