Name |
Heavy duty industrial drive shaft |
|
Type |
SWC-BF, SWC-BH, SWC-CH, SWC-DH, SWC-WD, SWC-WF, SWC-WH |
|
Quality Guarantee |
TS16949 |
|
Use for |
Use for rolling mill , marine drives, crane and so on |
|
Material |
Steel 45#, 60#, As per customer's requirment |
|
Production Standard |
According drawing or sample to manufacturing. OEM is available too |
|
Manufacturing Method |
Casting or forging, machining |
|
Surface Finish |
Heat treatment, rust prevention |
|
Inspection |
The production is inspected OK before package |
|
Inspection Method |
Assembly shaft with dynamic balance test to avoid virbration |
|
|
Spare parts check measurement |
|
Model |
Rotary DiameterD |
Nominal Torque Tn KN.m |
Fatigue Torque Tf KN.m |
Axial Angle α ≤ |
Size mm |
||||||||
|
D1 |
D2 |
D3 |
Lm |
n-d |
K |
t |
b |
g |
|||||
|
SWC100 |
100 |
1.6 |
0.8 |
25º |
84 |
57 |
60 |
55 |
6-9 |
7 |
2.5 |
- |
- |
|
SWC120 |
120 |
4.5 |
2.25 |
25º |
102 |
75 |
70 |
65 |
8-11 |
8 |
2.5 |
- |
- |
|
SWC150 |
150 |
10 |
5 |
25º |
130 |
90 |
89 |
80 |
8-13 |
10 |
3.0 |
- |
- |
|
SWC180 |
180 |
20 |
10 |
25º |
155 |
105 |
114 |
110 |
8-17 |
17 |
5.0 |
- |
- |
|
SWC200 |
200 |
36 |
18 |
15º |
173 |
120 |
140 |
115 |
8-17 |
20 |
5.0 |
28 |
8.0 |
|
SWC225 |
225 |
50 |
25 |
15º |
196 |
135 |
152 |
120 |
8-17 |
20 |
5.0 |
32 |
9.0 |
|
SWC250 |
250 |
71 |
35.5 |
15º |
218 |
150 |
168 |
140 |
8-19 |
25 |
6.0 |
40 |
12.5 |
|
SWC285 |
285 |
100 |
50 |
15º |
245 |
170 |
184 |
160 |
8-21 |
27 |
7.0 |
40 |
15.0 |
|
SWC315 |
315 |
140 |
70 |
15º |
280 |
185 |
219 |
180 |
10-23 |
32 |
8.0 |
40 |
15.0 |
|
SWC350 |
350 |
200 |
100 |
15º |
310 |
210 |
267 |
194 |
10-23 |
35 |
8.0 |
50 |
16.0 |
|
SWC390 |
390 |
280 |
140 |
15º |
345 |
235 |
267 |
215 |
10-25 |
40 |
8.0 |
70 |
18.0 |
About us
We have more than 17 years experience of Spare parts, especially on Drive Line Parts.
We deeply participant in the Auto Spare parts business in Hangzhou city which is the most import spare parts production area in China.
We are supply products with good cost performance for different customers of all over the world.
We keep very good relationship with local produces with the WIN-WIN-WIN policy.
Factory supply good and fast products;
We supply good and fast service;
And Customers gain the good products and good service for their customers.
This is a healthy and strong equilateral triangle keep Hangzhou Speedway going forward until now.
Address
Luotuo Industrial Area, Zhenhai District, Ningbo City, China
